Horizontal Injection Moulding Machine (E Series)
The E Series is a range of horizontal plastic injection moulding machines from Pratishna Engineers, built for production moulding of small and medium plastic components. The series spans 75 to 180 tons across six models, each with two or three screw options, so manufacturers can match clamping force and injection capacity to the specific component and mould.
Pratishna Engineers is one of the top and trusted E Series horizontal injection moulding machine manufacturers in India. The Mumbai-based company has 35+ years of experience and has supplied 9,000+ machines to 1,000+ customers, offering the E Series for small and medium parts across household, electrical, packaging, automotive and agricultural applications, backed by in-house engineering and after-sales support.
Across the range, screw diameters run from 27 to 45 mm, shot weights from 82 to 315 g (PS) and injection pressure up to 2,645 kg/cm², with daylight openings from 625 to 900 mm and platens from 550 × 510 mm to 725 × 650 mm. Buyers should select a model by clamping force, shot weight, screw diameter, injection pressure, mould dimensions, cycle time, material and production volume, not tonnage alone.
- Clamping force
- 75 – 180 T
- Models
- 6
- Shot weight
- Medium
Need Help Selecting an E Series Machine?
Contact Pratishna Engineers to discuss your plastic injection moulding requirements and request E Series specifications, application guidance and a quotation.
E Series Horizontal Injection Moulding Machines by Tonnage
The Pratishna E Series is available in six clamping-force options: 75, 100, 125, 150, 165 and 180 tons. Each model is built for reliable, repeatable moulding, with the injection unit, clamping system and controls matched to the tonnage. Select a model according to your component, mould size, number of cavities, shot weight and production requirement.
- 75 TonE-75Screw optionsØ27 · Ø32Shot weight82 – 116 gView specs →
- 100 TonE-100Screw optionsØ32 · Ø35Shot weight126 – 151 gView specs →
- 125 TonE-125Screw optionsØ35 · Ø38Shot weight151 – 178 gView specs →
- 150 TonE-150Screw optionsØ35 · Ø38 · Ø40Shot weight186 – 243 gView specs →
- 165 TonE-165Screw optionsØ40 · Ø45Shot weight249 – 315 gView specs →
- 180 TonE-180Screw optionsØ40 · Ø45Shot weight249 – 315 gView specs →
E Series specifications by model
Screw diameter and shot weight are shown for each injection unit option on that model. The E-150 offers three.
Locking unit | E-75 | E-100 | E-125 | E-150 | E-165 | E-180 | |
|---|---|---|---|---|---|---|---|
| Specification | Unit | ||||||
| Mould clamping force | Tons | 75 | 100 | 125 | 150 | 165 | 180 |
| Space between tie bars (H × V) | mm | 350 × 323 | 376 × 344 | 410 × 345 | 440 × 420 | 460 × 421 | 480 × 424 |
Injection unit | E-75 | E-100 | E-125 | E-150 | E-165 | E-180 | |
|---|---|---|---|---|---|---|---|
| Specification | Unit | ||||||
| Screw diameter | mm | 27 / 32 | 32 / 35 | 35 / 38 | 35 / 38 / 40 | 40 / 45 | 40 / 45 |
| Max. shot weight (PS) | g | 82 / 116 | 126 / 151 | 151 / 178 | 186 / 219 / 243 | 249 / 315 | 249 / 315 |
General | E-75 | E-100 | E-125 | E-150 | E-165 | E-180 | |
|---|---|---|---|---|---|---|---|
| Specification | Unit | ||||||
| Total connected load | kW | 17.5 | 18.5 | 18.5 | 23.7 | 31.8 | 31.8 |
Looking for the Right Injection Moulding Machine?
Tell us your production requirements and get a suitable Pratishna machine recommendation.
Why Choose Pratishna Engineers?
- Application-Based Machine Selection
- In-House Engineering & Manufacturing
- Multiple Machine Series
- Production-Focused Solutions
- End-to-End Technical Support
- Industry-Specific Solutions
- Machine Lifecycle Support
About Pratishna Engineers: Injection Moulding Machine Manufacturer in India
Pratishna Engineers Limited is a Mumbai-based manufacturer of plastic injection moulding machines in India, with 35+ years of machine-building experience. The company has in-house capabilities for machine design, manufacturing, assembly, testing and service, providing injection moulding solutions for different plastic processing requirements.
Pratishna Engineers manufactures horizontal, PET, special purpose, two-platen (PHM Series), hybrid and vertical injection moulding machines. Machines are configured according to the plastic component, mould, material, production volume and application requirements.
With 9,000+ machines supplied to 1,000+ customers, Pratishna Engineers serves manufacturers across automotive, packaging, electrical and electronics, medical, consumer products, agriculture and industrial applications in India and international markets.
- 9,000+
- Machines Supplied
- 1,000+
- Customers
- 35+
- Years of Engineering
- 25,000sq. ft.
- Manufacturing Facility
More About Horizontal Injection Moulding Machines
What Is a Horizontal Injection Moulding Machine?
A horizontal injection moulding machine is a type of injection moulding equipment in which the injection unit and mould are arranged along a horizontal axis.
Read More: What Is a Horizontal Injection Moulding Machine?
How Does a Horizontal Injection Moulding Machine Work?
In a horizontal machine, the injection unit and clamping unit sit along a horizontal axis. The mould mounts vertically on the platens, and finished parts are ejected and drop clear of the mould.
Read More: How Does a Horizontal Injection Moulding Machine Work?
Horizontal vs Vertical Injection Moulding Machines: Key Differences
The difference is the axis on which the clamp acts, and it changes what each machine is good at.
Read More: Horizontal vs Vertical Injection Moulding Machines: Key Differences
Important Specifications to Consider Before Buying a Horizontal Injection Moulding Machine
Choosing a horizontal injection moulding machine should be based on the component and moulding process rather than machine tonnage alone.
Read More: Important Specifications to Consider Before Buying a Horizontal Injection Moulding Machine
Applications of Horizontal Injection Moulding Machines
Horizontal machines cover the large majority of injection-moulded components, including household items, packaging, electrical parts, automotive components, agricultural and irrigation parts and general engineering components.
Read More: Applications of Horizontal Injection Moulding Machines
Injection Moulding Machine Buyer Resources
Download practical resources to help you select, size and specify the right machine.
- Image to be provided by client
E Series Catalogue
The E Series range from 75 to 180 tons, with model and screw options, main features and applications.
Download PDFPDF · 2.9 MB
E Series Specification Sheet
Actual Pratishna E Series data for every model and screw option: screw diameter, shot weight, injection pressure and rate, clamping force and stroke, mould thickness, daylight, tie-bar space, platen size, ejector, motor power, weight and floor space.
Injection Moulding Machine Selection Guide
A step-by-step guide covering the key inputs needed to select the right machine: product weight, projected area, number of cavities, plastic material, required clamping force, shot / injection capacity, mould dimensions, production quantity, cycle time and automation requirement.
Download PDFPDF · 265 KB
FAQs / Buyer Questions
The answers our engineers give most often, before an E Series specification is agreed.
What Is the Pratishna E Series Horizontal Injection Moulding Machine?
The E Series is a range of horizontal plastic injection moulding machines from Pratishna Engineers, available from 75 to 180 tons across six models, designed for small and medium plastic components.What Clamping-Force Range Does the E Series Cover?
The E Series covers six models: 75, 100, 125, 150, 165 and 180 tons.Which E Series Model Is Suitable for My Product?
The suitable model depends on your projected area, required clamping force, shot weight, mould dimensions, number of cavities and production volume. Share these details and Pratishna Engineers will recommend an appropriate model.Why Does Each E Series Model Offer Two or Three Screws?
A smaller screw gives higher injection pressure for thin walls and long flow paths, while a larger screw gives more shot weight. On the E-75, for example, the 27 mm screw reaches 2,500 kg/cm² with an 82 g shot, and the 32 mm screw gives a 116 g shot at 1,780 kg/cm².
What Products Can Be Manufactured on E Series Machines?
E Series machines are used for household products, electrical and electronic parts, packaging components, closures, small automotive parts, agricultural and irrigation parts and general industrial plastic components.What Plastic Materials Can the E Series Process?
Depending on the machine configuration, the E Series can process thermoplastics such as PP, PE, ABS, PS, nylon, PC, POM and other engineering plastics. Material-specific screw and barrel requirements should be evaluated before selection.What Is the Difference Between the E, C and H Series?
The E Series (75 to 180 tons) suits small and medium parts. The C Series (140 to 320 tons) is built for container making and thin-wall packaging, and the H Series (120 to 350 tons) is built for household articles and larger parts.Does Pratishna Provide Installation and Support for E Series Machines?
Yes. Pratishna Engineers provides installation, commissioning, operator training and after-sales technical support, along with spare parts, as part of its machine lifecycle services.
Related Blogs, Guides & Articles
Getting the Most From Multi-Cavity Moulds on 75 to 180 Ton Machines
Plan a multi-cavity mould for a 75 to 180 t machine: clamp per cavity, runner balance, cooling and hourly output, with a worked 4 vs 8 cavity check.
Injection Moulding Machine Tonnage Selection: Matching 75 to 180 Tons to Your Part
Injection moulding machine tonnage selection from 75 to 180 t: projected area, tonnage factor by resin, mould fit and a worked clamp check.
Injection Moulding Machine Upgrade: When to Move to a Container or Houseware Machine
Plan an injection moulding machine upgrade when clamp, shot, mould size or fill speed keep falling short. Signs, energy cost and a worked tub check.
Screw Diameter Choice: Shot Weight vs Injection Pressure on 75 to 180 Ton Machines
Shot weight vs injection pressure: how screw diameter trades one for the other on 75 to 180 t machines, with a worked screw check for a thin-wall part.
